Novy Pureline Frame 15009 90cm Island Hood | Black

TheNOVY Pureline Frame 90cm Island Hood – BlackIt is a sophisticateddecorative island hood with integrated lightingIdeal for contemporary kitchens that combine functionality and design. Its metal structure with integrated shelving and LED lights makes it a decorative piece as well as efficient in extraction.

1. General dimensions

•Product dimensions (LxWxH):872 x 556 x 800 mm
•Fixed height of the extraction body:800 mm
•Recommended installation height (countertop–hood):
- Induction hob: 650 – 850 mm
- Gas stove: 650 – 850 mm
- Electric/ceramic hob: 650 – 850 mm
•Air outlet/engine position:Superior
•Net weight:56 kg

2. Decorative structure

•Number of metal structures:3
•Dimensions of the structure (LxWxH):25 x 806 x 800 mm
•Bottom shelf (opening):845 x 485 mm
•Top shelf (opening):401 x 248 mm
•Shelf material thickness:18 – 25 mm

3. Extraction and noise levels

•Number of speeds:3 + Power function
•Automatic stop function after 3h
•Delayed stop:30 min
•Extraction flow rate (EN 61591):
- Speed ​​1: 251 m³/h
- Speed ​​2: 363 m³/h
- Speed ​​3: 423 m³/h
- Maximum power (Boost): 497 m³/h
•Sound level (dB(A)):
- Speed ​​1:47
- Speed ​​2: 55
- Speed ​​3: 58
- Intensive: 61

4. Functional and ambient lighting

•Functional LED lighting (dimmable):
- Number of light points: 4
- Total consumption: 8 W
- Color temperature: 2700K / 4000K
•LED shelf lighting (adjustable):
- Number of light points: 3
- Total consumption: 6 W
- Color temperature: 2700K / 4000K

5. Control and connectivity

•Controls:Electronic keypad + remote control
•Standard InTouch function:Compatible with NOVY hobs
•Grease filter cleaning indicator and recirculation
•Grease filters included:2 units (ref. 6830020)

6. Technical data

•Maximum power:123 W
•Voltage:220–240 V
•Frequency:50–60 Hz
•Power cord length:1.8 m

7. Purchase assistance

TheNOVY Pureline Frame 90 cmIt's more than a bell: it's adecorative element with high extraction performanceand sculptural design. Ideal for open kitchens and spaces that integrate technology and contemporary design.

To learn more about installation, spare parts, or customization, we invite you tocontact our team of professionalsThe complete technical specifications are available in the Downloads section of our website.
