Novy Panorama Pro surface hood 120 cm | Black

TheNOVY Panorama 120 Pro extractor hood with integrated induction hob (5-zone model)It is a118cm integrated cooking and extraction solution, which combines aHeight-adjustable vertical retractable hoodwith a5-zone induction hobincluding a high-power round central zone. This system is designed to offer performance, elegance, and seamless integration into high-end modern kitchens.

Thanks to its discreet design and advanced features, this unit is ideal for high-end residential projects.

1. General dimensions

Extractor hood
•Dimensions (LxWxH):1100 x 162 x 760–840 mm
•Adjustable height of the extraction tower:10, 20, 30 cm or freely adjustable
•Integrated motor and built-in soundproofing
•Air outlet:89 x 222 mm (front or rear center)
•Number of escapes:2
•Total weight (complete unit):56 kg

2. Integrated induction hob

•Glass:Opaque black with rounded edges
•Total size:1180 x 520 x 65 mm
•Facility:Flush or countertop
•Recessed opening:
- Countertop dimensions: 1160 x 490 mm
- Flush: 1184 x 524 x 6 mm

3. Cooking zones

•Number of zones:5 in total
- 4 octagonal zones (240 x 200 mm) of 2100/3000 W
- 1 round central zone (280 mm) of 2300/3000 W
•Advanced features:
- 9 power levels + Power + Super Power
- Timer per zone and minute counter
- Stop&Go, bridging function (automatic/manual Flexzone), keep warm (70 °C)
- Automatic cooking and container detection
- Child lock and residual heat indicator
- Grill function included

4. Extractor hood – technical specifications

•Energy efficiency class:B
•Sound pressure (air outlet):
- Minimum: 22 dB / 35 dB
- Continuous: 48 dB / 61 dB
- Intensive: 56 dB / 70 dB
•Sound pressure (recirculation):
- Minimum: 25 dB / 39 dB
- Intensive: 58 dB / 71 dB
•Quantity of air (EN 61591):
- Minimum: 237 m³/h
- Intensive: 1009 m³/h
- Maximum efficiency point: 446 m³/h

5. Electricity consumption and connection

•Maximum power induction hob:10,400 W
•Maximum power kitchen hood:450 W
•Electrical connection of the bell:230 V, Schuko cable 1.2 m
•Induction hob connection:230 V / 400V – 1N / 2N / 3N, 2 m cable
•Standby consumption:<0.5 W

6. Available accessories

•Recirculation drawers with Monoblock filter H 98 mm(98 x 1100 x 290 mm):
- White – ref. 7941400
- Black – ref. 7942400
- Stainless Steel – ref. 7943400

7. Purchase assistance

TheNOVY Panorama 120 Pro 42120It is a high-performance solution that combines innovation, design and functionality in a single premium kitchen appliance.

For more information on installation, furniture compatibility, or accessories, please feel free to contact us.contact our team of professionalsThe complete technical specifications are available in the Downloads section of our website.
